From Q235 steel coil to hot-dip galvanized conical pole to installed LED floodlight system — BSW controls the whole chain in its 50,000+ m² factory, which is why government projects trust us with 25m+ masts.
Get High Mast Pole Quote WhatsApp: +86 152 9848 1418| Item | Specification |
|---|---|
| Height | 15m / 20m / 25m / 30m / 35m / 40m |
| Shape | Conical or dodecagonal/octagonal tapered, multi-section slip-joint |
| Material | Q235B steel, hot-dip galvanized (ISO 1461) + electrostatic polyester powder coating |
| Wind rating | Engineered per project site wind load (typ. 120–180 km/h) |
| Floodlights | LED 400W–2000W, 150 lm/W, asymmetric optics, optional solar hybrid |
| Access | Internal or external climbing ladder, safety cage, maintenance winch system |
Wide-area floodlighting for football fields and sports complexes with asymmetric optics and winch maintenance.
High-output lighting for container terminals and cargo yards, including 35m–40m masts with lifting systems.
Interchange and toll-station lighting reducing pole count versus conventional street lighting layouts.
Apron and perimeter area lighting with engineered wind-load and aviation-adjacent configurations.
Urban plaza and roundabout lighting for municipal beautification and safety programs.
Factory compounds, mining sites and large storage areas requiring wide, uniform coverage.
BSW is a manufacturing group, not a trading company — pole rolling, galvanizing and floodlight assembly happen in our own plant.
| Capability | Detail |
|---|---|
| Manufacturer since 2005 | 20+ years producing poles and outdoor lighting systems in Gaoyou, Jiangsu |
| 50,000+ m² factory | In-house rolling, welding, galvanizing and aging test lines |
| In-house pole production | 3m–40m galvanized steel poles with inspection at every stage |
| Dual Class A qualifications | Urban & Road Lighting Engineering Grade A and Security Engineering Grade A |
| Export experience | Delivered to 55+ countries; UAE 25m high mast delivered and commissioned |
| Engineering service | Foundation drawings, wind-load calculation, DIALux design and BOQ support |
Foundation drawings, wind-load calculation, photometric (DIALux) design and BOQ support for tender documents.
In-house rolling, welding and galvanizing with inspection at every stage — Dual Class A qualified contractor.
Sectioned shipping with protective packaging, installation supervision and commissioning guidance available.
Galvanized 25m high masts with LED floodlights for interchanges and logistics yards in a high-temperature desert environment — delivered and commissioned.
Wind-solar hybrid street lights with 300W wind turbines for desert highways, 24h autonomy.
Standard 15m–30m stadium and highway masts; 35m masts with lifting systems for airport and seaport applications.
We manufacture 15m, 20m, 25m, 30m, 35m and 40m high mast poles in conical or octagonal tapered multi-section designs, with wind-load engineering per project site.
Poles are made of Q235B steel with hot-dip galvanizing to ISO 1461, plus electrostatic polyester powder coating. Coastal C5-grade options are available for salt-fog environments.
Yes. Configurations include internal or external climbing ladder, safety cage, and a maintenance winch (raising/lowering) system so floodlight frames can be serviced from the ground.
LED floodlights from 400W to 2000W at approx. 150 lm/W with asymmetric optics; solar hybrid configurations are available for off-grid sites.
Foundation drawings, wind-load calculation, photometric (DIALux) design and BOQ support are provided for tender and EPC bid packages.
Send your mast height, floodlight layout and site wind conditions — our engineers reply within 24 hours with a structural and lighting proposal.
Get High Mast Pole Quote Email: cindy@solarlightbsw.com
